Vertical Cable offers the LC Fiber Optic Keystone Coupler in Aqua, designed for high-speed 10G networking applications. With its white color, this keystone coupler seamlessly integrates into various networking setups. Trust Vertical Cable for reliable and high-performance fiber optic connectivity solutions.
- Fiber types-SM 9/125, MM 50/125, MM 62.5/125
- Plug types-UPC, APC
- Zirconia ceramic split sleeves
- Compatible with all Vertical Cable faceplates and surface-mount boxes designed to mount keystone modules
- Insertion Loss: 0.3 dB or lower (when used with standard-compliant plugs)
- Return Loss: UPC: ≥55 dB (when used with standard-compliant plugs); APC: ≥65 dB (when used with standard-compliant plugs)
- Bezel material: ABS (acrylonitrile butadiene styrene)
- Bezel compliance: Regulation (EC) No 1907/2006 (REACH); Directive 2011/65/EU Am. 2015/863/EU (RoHS2)
- Adapter compliance: IEC 61754-2 (type BFOC/2.5 connector family (ST)); IEC 61754-4 (type SC connector family); IEC 61754-13 (type FC-PC connector family); IEC 61754-20 (type LC connector family); Regulation (EC) No 1907/2006 (REACH); Directive 2011/65/EU Am. 2015/863/EU (RoHS2); ANSI/UL 94 V-0
