SPECIFICATIONS:

INPUT:
– 12VDC APPLICATIONS USE TP1640, T2428100
– 24VDC APPLICATIONS USE T2428100

OUTPUT:
– 12VDC OR 24VDC SELECTABLE OUTPUT
– 2.5A CONTINUOUS SUPPLY CURRENT
– FILTERED AND ELECTRONICALLY REGULATED OUTPUT
– SHORT CIRCUIT AND THERMAL OVERLOAD PROTECTION

BATTERY BACKUP:
– BUILT-IN CHARGER FOR SEALED LEAD ACID OR GEL TYPE BATTERIES
– AUTOMATIC SWITCH OVER TO STAND-BY BATTERY WHEN AC FAILS
– BATTERY SHORT CIRCUIT PROTECTION (CIRCUIT BREAKER)

SUPERVISION:
– AC FAIL SUPERVISION (FORM “C” CONTACTS)
– LOW BATTERY SUPERVISION (FORM “C” CONTACTS)

VISUAL INDICATORS:
– AC INPUT AND DC OUTPUT LED INDICATORS
