SPECIFICATIONS:

INPUT VOLTAGE:
– 6VDC OR 12VDC OPERATION
– CURRENT DRAW RANGE FROM 0.3A TO 1.22A BASED ON SPEAKER RESISTANCE AND SUPPLY VOLTAGE

FEATURES:
– TWO (2) CHANNEL OPERATION – STEADY OR YELP
– VERY LOW CURRENT DRAW
– PARALLEL OR SERIES SPEAKER WIRING
– 103 DB @ 10 FT. @ 6V – 8 OHMS
– 105 DB @ 10 FT. @ 6V – 4 OHMS
– 106 DB @ 10 FT. @ 12V – 8 OHMS
– 111 DB @ 10 FT. @ 12V – 4 OHMS

ELECTRICAL:
– OPERATING TEMP: – 25° C TO 55° C ( – 13° F TO 131° F)
– STORAGE – 25° C TO 70° C ( – 13° F TO 158° F)
– RELATIVE HUMIDITY 85% +/- 5%
– SYSTEM INPUT VA REQUIREMENT: 14.6A
