Intellinet Media Converter Industrial Gigabit Ethernet 10/100/1000 to Unloaded SFP Slot 12 to 56VDC

$124.99

  • One 10/100/1000 RJ45 port supporting a maximum distance of 100 m (300 ft.)
  • One SFP port for 1000Base-X optical transceiver modules and distances up to 120 km (75 mi.)
  • IP40 slim-type metal housing to withstand harsh industrial conditions
  • Option for DIN-rail installation
  • Two redundant DC inputs (12 – 56 V) with terminal block
  • Requires industrial power supply (not included)
  • Rated for shock (IEC 60068-2-27), freefall (IEC 60068-2-32) and vibration (IEC 60068-2-6)
  • Supports full-duplex and half-duplex modes with autonegotiation
  • Suitable for extreme operating temperatures of -40 to 85ºC (-40 to 185ºF)
  • Supports 8k MAC address entries with Auto-learning and Auto-aging
  • Buffer memory of 1 MByte
  • Supports jumbo frames up to 10 kBytes
  • Fanless design for silent operation
  • Fully NDAA-compliant
  • Three-year warranty

Out of stock

SKU: INTR-508971 Categories: ,

Intellinet Industrial Gigabit Ethernet Media Converter | 10/100/1000 to Unloaded SFP Slot | 12-56VDC

Ensure reliable and rugged fiber-to-Ethernet conversion with the Intellinet Industrial Gigabit Ethernet Media Converter (10/100/1000 to Unloaded SFP Slot, 12-56VDC), designed for harsh environments, industrial applications, and mission-critical networks. This high-performance media converter supports gigabit speeds and features an unloaded SFP slot, allowing for customizable fiber transceiver options while operating within a wide voltage range (12-56VDC) for flexible power input.

Features:

  • Gigabit Ethernet (10/100/1000 Mbps) to fiber conversion for high-speed networking
  • Unloaded SFP slot for flexible fiber transceiver selection (single-mode or multi-mode)
  • Industrial-grade design with wide operating temperature support
  • 12-56VDC power input range for versatile deployment in industrial environments
  • Rugged metal housing for durability in harsh conditions
  • Plug-and-play installation for easy setup and integration
  • Ideal for manufacturing, transportation, energy, and enterprise networking

Choose the Intellinet Industrial Gigabit Ethernet Media Converter (10/100/1000 to Unloaded SFP Slot, 12-56VDC) for a robust, scalable, and high-performance industrial networking solution!

Weight 0.660 lbs

Brand

Intellinet Network Solutions
